- TypeDesktop
- FunctionCopy, print, scan, optional: fax
- Print technologyLaser colour and b/w
- Original formatmax A3 from platen glass
- Print speed (A4, Simplex) B/W25 b/w-pages/min.
- Print speed (A3, Simplex) B/W12 b/w-pages/min.
- Copy speed (A4, Simplex) B/W25 b/w-pages/min.
- Copy speed (A3, Simplex) B/W12 b/w-pages/min.
- Print speed (A4, Simplex) Colour25 colour pages/min
- Print speed (A3, Simplex) Colour12 colour pages/min
- Copy speed (A4, Simplex) Colour25 colour pages/min
- Copy speed (A3, Simplex) Colour12 colour pages/min
- 1st page (printing, colour)9.2 seconds
- 1st page (printing, b/w)7 seconds
- 1st page (copying, colour)8.5 seconds
- 1st page (copying, b/w)6.4 seconds
- Warm-up time18 seconds
- Copy resolutionmax 600 x 600 dpi
- Greyscales256
- Paper feed (Universal cassettes amount)2 x 500 sheet universal cassettes
- Paper feed (1st cassette types)A6R-A4
- Paper feed (2nd cassette types)A6R-SRA3
- Paper feed (Multi-Bypass amount)1 x 500 sheet
- Paper feed (Multi-Bypass types)A6R-A4, Banner [305 x 1,219 mm]
- Paper feed (print-only)SRA3 and banner
- Paper weights (Universal cassette min)52 g/m²
- Paper weights (Universal cassette max)300 g/m²
- Paper weights (Multi-Bypass min)52 g/m²
- Paper weights (Multi-Bypass max)300 g/m²
- Paper weights (Duplex min)64 g/m²
- Paper weights (Duplex max)256 g/m²
- Paper output500 sheet A4
- System memory (RAM)4 GB
- System memory (SSD)32 GB
- System memory (Optional)320 GB HDD
- Continuous copying (min)1
- Continuous copying (max)9999
- Zoom (min)25 %
- Zoom (max)400 %
- Zoom (step)1 %
- FunctionsAdjustable colour touch screen (10.1 inch), duplex, 1000 management codes, skip blank pages, motion sensor, etc.
- Dimensions (height)790 mm
- Dimensions (width)602 mm
- Dimensions (depth)665 mm
- Weight90 kg
- Mains voltage220/240 V
- Utility frequency50/60 Hz
- Power consumption (max)1750 W
- Power consumption (busy)455 W
- Power consumption (standby)50 W
- Power consumption (sleep)0.7 W
- Power consumption (TEC)0.34 kwh/week
- SafetyGS/TÜV, CE, trusted platform modul (TPM)
- TypeIntegrated within the system
- Print formatA6R-SRA3
- Print resolution (min)600 x 600 dpi
- Print resolution (max)1,200 x 1,200 dpi
- ProcessorFreescale QorIQ T1024 (Dual Core) 1.0 GHz
- InterfacesUSB 3.0, USB 2.0, 10/100/1000BaseTX, USB host, NFC
- Network protocolsTCP/IP, Net BEUI
- Operating systemsWindows 7, Windows 8.1, Windows 10, Server 2008, Server 2008 R2, Server 2012, Server 2012 R2, Server 2016, Novell NetWare, Linux, Mac ex OS 10.9
- EmulationsPCL6 (PCL 5e, XL), KPDL 3 (PostScript 3 compatible), XPS, PDF 1.7, PRESCRIBE Ilc
- Functions200 dpi, USB direct printing, PDF/XPS direct printing, printing of e-mails, private printing, barcode printing, Mobile Print (Android, iOS)/Apple AirPrint, Google Cloud Print
- Scan typeCCD colour and b/w
- Scan formatmax A3
- Scan speed (Feeder 1, simplex, colour)100 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, b/w)100 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, colour)180 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, b/w)180 DIN-A4-image pages/min. in 300 dpi
- Optional feeder 1DP-7130
- Scan resolution200 dpi, 300 dpi, 400 dpi, 600 dpi
- Scan modePhoto, text, photo/text, optimised for OCR
- File typesTIFF, JPEG, PDF, PDF/A, high compression PDF, encrypted PDF, XPS, OpenXPS
- Interfaces10/100/1000BaseTX
- Network protocolTCP/IP
- Operating systemsWindows 7, Windows 8.1, Windows 10, Server 2008, Server 2008 R2, Server 2012, Server 2012 R2, Server 2016
- FunctionsScan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP
- Typeoptional Fax System 12
- CompatibilitySuper G3
- Original formatmax A3
- Modem speed33.6 kbps
- Transmission speed3 seconds or less using JBIG
- Compression methodJBIG, MMR, MR, MH
- Fax resolutionStandard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi), 600 x 600 dpi
- Fax memory170 MB
- Abbreviated dial2000 numbers
- One touch dial1000 numbers
- Group dial500 numbers
- Operating systemsWindows 7, Windows 8.1, Windows 10, Server 2008, Server 2008 R2, Server 2012, Server 2012 R2, Server 2016
- FunctionsNetwork fax driver, automatic redialling, delayed transmission, max 2 fax kits for parallel transmission and reception
- Original feederDP-7100 document processor with automatic reverse function (A6R-A3, capacity: 140 sheet A4, paper weight 35-160 g/m²), DP-7120 document processor with automatic reverse function (A5R-A3, capacity: 50 sheet A4, paper weight 45-160 g/m²), DP-7110 document processor with simultaneous duplex scanning (A6R-A3, capacity: 270 sheet A4, paper weight 35-220 g/m²), DP-7130 document processor with simultaneous duplex scanning and multi-feed detection (A6R-A3, capacity: 270 sheet A4, paper weight 35-220 g/m²)
- Original platen coverPlaten cover type E (if document processor is not installed)
- FinisherDF-7100 internal finisher (capacity: 500 sheet A4, stapling max 50 sheet A4), DF-7120 (capacity: 1,000 sheet A4, stapling max 50 sheet A4),, DF-7110 (capacity: 4,000 sheet A4, stapling max 65 sheet A4), PH-7120 hole punch unit for DF-7100, PH-7C hole punch unit for DF-7120/7140, BF-730 brochure module for DF-7110 (max 20 sheet saddle stitching and folding A4/A3, tri-folding max 5 sheet A4), MT- 730 (B) Multi Tray für DF-7110
- Job SeparatorJS-7100 (100 sheet, 52-300 g/m², A6R - SRA3)
- Paper feedPF-7100 (2 x 500 sheet universal cassettes [A5R-SRA3]), PF-7110 (2 x 1,500 sheet large capacity cassette [A4]), PF-7120 (3,000 sheet large capacity tray [A4], side deck)
- Other optionsScan extension kit (A), Internet fax kit (A), Card authentication kit (B), Keyboard holder 10, Banner guide 10, UG-33 ThinPrint® kit, UG-34 Emulation option kit, IB-50 Gigabit Ethernet card, IB-51 WLAN card, IB-35 WLAN card, DT-730(B) Document tray, NK-7120 Numeric Keyboard (10 keys), cabinet no. 76, HD-12 (320 GB HDD)
