General
- TypeConsole Unit
- FunctionCopy, print, scan, optional: fax
- Print technologyLaser b/w
- Original formatmax A3 from platen glass
- Copy resolutionmax 600 x 600 dpi
- Greyscales256
- Paper feed (1st cassette types)A6R-SRA3
- Paper feed (2nd cassette types)A6R-SRA3
- Paper feed (Multi-Bypass types)A6R-SRA3, Banner [330,2 x 1.220 mm]
- Paper feed (Large Capacity Cassette amount)2 x 1,500 sheet
- Paper feed (Large Capacity Cassette 1 types)A4
- Paper feed (Large Capacity Cassette 1 types)A4
- Paper output250 sheet A4 (lower tray), 100 sheet A4 (lower tray), 70 Blatt (rechte Ausgabe)
- Printing resolution (max)1,200 x 1,200 dpi
- FunctionsAdjustable colour touch screen (10.1 inch), duplex, 1000 management codes, encryption/overwriting of hard disk data (Data Security Kit and Trusted Platform Module), secure boot and run time integrity check, trusted platform modul (TPM), skip blank pages, etc.
- Print speed (A4, Simplex) B/W105 b/w-pages/min.
- Print speed (A3, Simplex) B/W52 b/w-pages/min.
- Copy speed (A4, Simplex) B/W105 b/w-pages/min.
- Copy speed (A3, Simplex) B/W52 b/w-pages/min.
- Print speed (A4, Duplex) B/W105 b/w-pages/min.
- Print speed (A4, Duplex) B/W29 b/w-pages/min.
- Copy speed (A4, Duplex) B/W105 b/w-pages/min.
- Copy speed (A3, Duplex) B/W29 b/w-pages/min.
- 1st page (printing, b/w)3,5 seconds
- 1st page (copying, b/w)4,3 seconds
- Paper weights (Universal cassette min)52.0 g/m²
- Paper weights (Universal cassette max)300.0 g/m²
- Paper weights (Multi-Bypass min)52.0 g/m²
- Paper weights (Multi-Bypass max)300.0 g/m²
- Paper weights (Duplex min)52 g/m²
- Paper weights (Duplex max)256.0 g/m²
- Paper weights (Banner min)35 g/m²
- Paper weights (Banner max)220 g/m²
- System memory (RAM)7 GB
- System memory (SSD)256 GB
- Continuous copying (min)1.0
- Continuous copying (max)9999.0
- Zoom (min)25.0 %
- Zoom (max)400.0 %
- Zoom (step)1.0 %
Dimensions / Weight
- Dimensions (height)1.227 mm
- Dimensions (width)685 mm
- Dimensions (depth)660 mm
Environment
- Noise level (busy, b/w)57.9 dB(A)
- Noise level (standby)44.2 dB(A)
- Mains voltage220/240 V
- SafetyGS/TÜV, CE
- Utility frequency50/60 Hz
- Power consumption (busy)1.530 W
- Power consumption (max)2.400 W
- Power consumption (TEC)2.02 kwh/week
- Power consumption (standby)130 W
- Power consumption (sleep)0.5 W
Printing system
- Print resolution (max)1,200 x 1,200 dpi
- EmulationsKPDL 3 (PostScript 3 compatible), XPS, PRESCRIBE Ilc, PCL6 (PCL 5c, XL), Open XPS, PDF, PPML, XJDF/XJMF
- FunctionsUSB direct printing, PDF/XPS direct printing, printing of e-mails, private printing, barcode printing, SNMPv3, Mobile Print (Android, iOS)/Apple AirPrint, Mopria, Wi-Fi Direct®, Super Resolution Imaging (nur KXTreiber), EcoPrint, etc.
- Operating systemsWindows 8, Windows 8.1, Windows 10, Windows 11, Server 2012, Server 2012 R2, Server 2016, Server 2019, Server 2022, Chrome OS, Mac ab OS 10.14, Linux
- TypeIntegrated within the system
- InterfacesUSB 3.0, USB 2.0, 10/100/1000BaseTX, USB host, NFC, SD-Card Slot
- Print formatA6R-SRA3
Scanning system
- Scan speed (Feeder 1, duplex, b/w)300 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, b/w)150 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, colour)300 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, colour)150 DIN-A4-image pages/min. in 300 dpi
- Scan formatmax A3
- File typesTIFF, JPEG, PDF, PDF/A, high compression PDF, encrypted PDF, XPS, OpenXPS, MS Office/text-searchable PDF
- Interfaces10/100/1000BaseTX
- Network protocolTCP/IP
- Operating systemsWindows 8, Windows 8.1, Windows 10, Windows 11, Server 2012, Server 2012 R2, Server 2016, Server 2019, Server 2022, Chrome OS, Mac ab OS 10.14
- Scan modePhoto, text, photo/text, optimised for OCR
- FunctionsScan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP, Multi Crop Belegscan, OCR-Texterkennung, Cloud Capture Funktionalität, Document Guard, Farbe löschen, Image Defect Prevention, Scanfehler erkennen
- Scan typeCCD colour and b/w, CIS colour and b/w
- Scan resolution200 dpi, 300 dpi, 400 dpi, 600 dpi
Fax system
- One touch dial1000.0 numbers
- Group dial500.0 numbers
- Modem speed33.6 kbps
- Abbreviated dial2000.0 numbers
- Fax memory170.0 MB
- CompatibilitySuper G3
- Transmission speed3 seconds or less using JBIG
- FunctionsNetwork fax driver, automatic redialling, delayed transmission, max 2 fax kits for parallel transmission and reception
- Operating systemsWindows 8, Windows 8.1, Windows 10, Windows 11, Windows 11, Server 2012, Server 2012 R2, Server 2016, Server 2019, Server 2022, Chrome OS, Mac ab OS 10.14
- Compression methodJBIG, MMR, MR, MH
- Original formatmax A3
- Fax resolutionStandard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi), 600 x 600 dpi
Options
- Other optionsInternet fax kit (A), Card authentication kit (B), Keyboard holder 10, UG-33 ThinPrint® kit, UG-34 Emulation option kit, IB-37 WLAN card (IEEE802.11a/b/g/n/ac), NK-7120 Numeric Keyboard (10 keys), DT-730(B) Document tray, HD-16 (1 TB HDD), PH-7220 Locheinheit für DF-7200 und DF-7210, MT-7200 Multi Tray für DF-7200/DF-7210, IS-7200 Zuschießeinheit (kompatibel mit DF-7200/DF-7210), ZF-7200 Z-Falz Einheit (kompatibel mit DF-7200/DF-7210)
