General
- TypeDesktop
- FunctionCopy, print, scan, optional: fax
- Print technologyLaser b/w
- Original formatmax A3 from platen glass
- Original feeder50 sheet A4 (standard), min 140 x 182 mm, max 297 x 432 mm, 45-160 g/m² (simplex), 50-120 g/m² (duplex)
- Copy resolution600 x 600 dpi
- Greyscales256
- Paper feed (Universal cassettes amount)1 x 500 sheet
- Paper feed (1st cassette types)A5R-A3
- Paper feed (Multi-Bypass amount)100 sheet multi-bypass (A6R-A3)
- Paper feed (Multi-Bypass types)A6R-A3
- Paper output250 sheet A4
- Job Separator50 sheet A4 (standard)
- Printing resolution (min)600 x 600 dpi
- Printing resolution (max)1,200 x 1,200 dpi
- Functionsduplex, Print from/Scan to USB Stick, job reservation, N-up, favourites, 100 management codes, Colour touch screen (7 inch), Wi-Fi, etc., ID card copy, barcode printing, printing of e-mails, colour scanning, management codes, skip blank pages, Mobile Print (Android, iOS)/Apple AirPrint, NFC, PDF/XPS direct printing, secure boot and run time integrity check, SNMPv3, Adjustable colour touch screen (10.1 inch), trusted platform modul (TPM), USB direct printing, encryption/overwriting of hard disk data (Data Security Kit and Trusted Platform Module), Wi-Fi Direct®
- InterfacesUSB 2.0, 10/100/1000BaseTX, USB host (2), NFC, Wi-Fi
- EmulationsPCL6 (PCL 5c, XL), KPDL 3 (PostScript 3 compatible), PRESCRIBE Ile, PDF 1.7
- Network protocolsTCP/IP, Net BEUI
- Operating systemsWindows 8, Windows 8.1, Windows 10, Server 2012, Server 2012 R2, Server 2016, Server 2019, Server 2022, Chrome OS, Mac ab OS 10.14, Windows 11
- Print speed (A4, Simplex) B/W32 b/w-pages/min.
- Print speed (A3, Simplex) B/W17 b/w-pages/min.
- Print speed (A4, Duplex) B/W29 b/w-pages/min.
- Print speed (A4, Duplex) B/W11 b/w-pages/min.
- 1st page (printing, b/w)5.8 seconds
- 1st page (copying, b/w)5.8 seconds
- Paper weights (Universal cassette min)60 g/m²
- Paper weights (Universal cassette max)163.0 g/m²
- Paper weights (Multi-Bypass min)45.0 g/m²
- Paper weights (Multi-Bypass max)256.0 g/m²
- Paper weights (Duplex min)60.0 g/m²
- Paper weights (Duplex max)120 g/m²
- System memory (RAM)2 GB
- System memory (RAM max)2 GB
- Continuous copying (min)1.0
- Continuous copying (max)999.0
- Zoom (min)25.0 %
- Zoom (max)400.0 %
- Zoom (step)1.0 %
Dimensions / Weight
- Dimensions (height)590 mm
- Dimensions (width)585 mm
- Dimensions (depth)688 mm
Environment
- Noise level (busy, b/w)44.9 dB(A)
- Mains voltage220/240 V
- SafetyGS/TÜV, CE
- Utility frequency50 Hz
- Power consumption (busy)410.0 W
- Power consumption (max)1270.0 W
- Power consumption (TEC)0.29 kwh/week
- Power consumption (standby)65.0 W
- Power consumption (sleep)0.5 W
Printing system
- Print resolution (max)1,200 x 1,200 dpi
- EmulationsPCL6 (PCL 5c, XL), KPDL 3 (PostScript 3 compatible), PRESCRIBE Ile, PDF 1.7, XPS
- FunctionsUSB direct printing, printing of e-mails, PDF/XPS direct printing, private printing, barcode printing, Mobile Print (Android/iOS), Apple AirPrint, Google Cloud Print, Wi-Fi
- Operating systemsWindows 7, Windows 8, Windows 8.1, Windows 10, Server 2008 R2, Server 2012 R2, Server 2016, Novell NetWare, Linux, Mac ex OS 10.5, Windows 11
- TypeIntegrated within the system
- ProcessorARM Cortex-A9 Dual core 1.2 GHz
- InterfacesUSB 2.0, 10/100/1000BaseTX, USB host (2), NFC, Wi-Fi
- Print formatA6R-A3
- Network protocolsTCP/IP, Net BEUI
Scanning system
- Scan speed (Feeder 1, duplex, b/w)16.0 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, b/w)50.0 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, colour)16.0 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, colour)50.0 DIN-A4-image pages/min. in 300 dpi
- Scan formatmax A3
- File typesTIFF, PDF, XPS, OpenXPS, high compression PDF, JPEG
- Interfaces10/100/1000BaseTX, USB 2.0
- Network protocolTCP/IP
- Operating systemsWindows 8, Windows 8.1, Windows 10, Server 2012 R2, Server 2016, Server 2012, Server 2019, Server 2022, Chrome OS, Mac ab OS 10.14, Windows 11
- Scan modePhoto, text, photo/text, optimised for OCR
- FunctionsScan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP, Multi Crop Belegscan, TWAIN-Scan (via USB
- Scan typeCIS colour and b/w
- Scan resolution200 dpi, 300 dpi, 400 dpi, 600 dpi
Fax system
- One touch dial100.0 numbers
- Group dial50.0 numbers
- Modem speed33.6 kbps
- Abbreviated dial300 numbers
- Fax memory16.0 MB
- Fax memory (image)12.0 MB
- CompatibilitySuper G3
- Transmission speed3 seconds or less using JBIG
- FunctionsNetwork fax driver, automatic redialling, delayed transmission
- Typeoptional Fax System 13
- Operating systemsWindows 8, Windows 8.1, Windows 10, Server 2008 R2, Server 2012 R2, Server 2016, Server 2012, Server 2019, Server 2022, Chrome OS, Mac ab OS 10.14, Windows 11
- Compression methodJBIG, MMR, MR, MH
- Original formatmax A3
- Fax resolutionStandard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi)
Options
- Other optionsScan extension kit (A), Card authentication kit (B), UG-33 ThinPrint® kit, cabinet no. 62, HD-17 SSD (64 GB), HD-18 SSD (256 GB), HD-19 SSD (512 GB), IB-37 WLAN card (IEEE802.11a/b/g/n/ac), IB-38 W-LAN card**** (IEEE802.11 b/g/n Wi-Fi direct)
- Paper feedPF-470 (1 x 500 sheet universal cassettes (A5R-A3)), PF-471 (2 x 500 sheet universal cassettes (A5R-A3))
